Electric wrenches are mainly used in the steel structure installation industry. They are specially used to install high-strength bolts of steel structure. High-strength bolts are used to connect steel structure joints, usually in the form of bolt groups. High strength bolts can be divided into torsion shear type and large hexagon type. There are four kinds of national standard torsion shear high strength bolts: M16, M20, M22 and M24, and two kinds of non-national standard M27 and M30; The national standard large hexagon high-strength bolts are M16, M20, M22, M24, M27, M30, etc. Generally, the tightening of high-strength bolts should be first tightened and then finally tightened, and strict torque requirements are required in each step. Constant torque wrench is required for initial and final tightening of large hexagon high strength bolts Therefore, all kinds of electric wrenches are for various fastening needs.

冲击电动扳手主要是初紧螺栓的，它的使用很简单，就是对准螺栓扳动电源开关就行。电动扭剪扳手主要是终紧扭剪型高强螺栓的，它的使用就是对准螺栓扳动电源开关，直到把扭剪型高强螺栓的梅花头打断为止。电动定扭矩扳手既可初紧又可终紧，它的使用是先调节扭矩，再紧固螺栓。电动转角扳手主要也属于定扭矩扳手的一种，它的使用是先调节旋转度数，再紧固螺栓。电动角向扳手是一种专门紧固钢架夹角部位螺栓的电动扳手，它的使用和电动扭剪扳手原理一样。

The impact electric wrench is mainly used to initially tighten the bolt. Its use is very simple. Just aim at the bolt and pull the power switch. The electric torsion shear wrench is mainly used to finally tighten the torsion shear high-strength bolt. Its use is to align the bolt and pull the power switch until the plum blossom head of the torsion shear high-strength bolt is broken. The electric constant torque wrench can be tightened initially and finally. Its use is to adjust the torque first and then tighten the bolts. Electric angle wrench mainly belongs to a kind of constant torque wrench. Its use is to adjust the rotation degree first, and then tighten the bolt. The electric angle wrench is an electric wrench specially used to fasten the bolts at the included angle of the steel frame. Its use principle is the same as that of the electric torsion shear wrench.

电动扳手操作规程

Operating procedures for electric wrench

检验试验及保养

Inspection, test and maintenance

1、电动扳手的金属外壳应可靠接地，其外壳应有定期检验试验合格证，并在期限内。

1. The metal shell of the electric wrench shall be reliably grounded, and its shell shall be provided with regular inspection and test certificate within the time limit.

2、检查电动扳手机身安装螺钉紧固情况，若发现螺钉松了，应立即重新扭紧，否则会导致电动扳手故障。

2. Check the fastening of the mounting screws on the body of the electric wrench. If the screws are found to be loose, tighten them again immediately, otherwise the electric wrench will fail.

3、检查手持电动扳手两侧手柄完好，不开裂可破损，安装牢固。

3. Check that the handles on both sides of the hand-held electric wrench are intact, not cracked or damaged, and installed firmly.

以上就是为大家介绍的有关扭剪电动扳手的详细介绍,希望对您有所帮助.如果您有什么疑问的话,欢迎联系我们.我们将以的态度,为您提供服务

The above is the detailed introduction of the electric wrench for torsion and shear. I hope it will be helpful to you If you have any questions, please contact us We will provide you with professional service
