扭力扳手原理

来源:日期:2022-06-29 发布人:admin

扭矩扳手工作原理:是依据梁的弯曲原理、扭杆的弯曲原理和螺旋弹簧的压缩原理而设计的,能测量出作用在螺母上的力矩大小。扭矩扳手又叫力矩扳手、扭力扳手、扭矩可调扳手,是扳手的一种,一般分为三类:手动力矩扳手、气动扭力扳手和电动力矩扳手。扭矩扳手有一根长的弹性杆,其一端装着手柄,另一端装有方头或六角头,在方头或六角头上套装一个可换的套筒,用钢珠卡住。在顶端上还装有一个长指针。刻度板固定在柄座上,每格刻度值为1N。

Working principle of torque wrench: it is designed according to the bending principle of beam, the bending principle of torsion bar and the compression principle of spiral spring, and can measure the torque acting on the nut. Torque wrench, also called torque wrench, torque wrench and torque adjustable wrench, is a kind of wrench, which is generally divided into three categories: manual torque wrench, pneumatic torque wrench and electric torque wrench. The torque wrench has a long elastic rod, one end of which is equipped with a handle, and the other end is equipped with a square head or hexagonal head. A replaceable sleeve is sleeved on the square head or hexagonal head and clamped with a steel ball. There is also a long pointer on the top. The scale plate is fixed on the handle base, and the scale value of each grid is 1n.
澳门原料1688
什么是钢结构扭剪螺栓。一般来说,它是由热处理高强度钢35CrMo35碳钢材料等制成,可分为8.8级和10.9级,与普通螺栓不同,螺栓必须在8.8级以上。
What is steel structure torsional shear bolt. Generally speaking, it is made of heat-treated high-strength steel 35crmo35 carbon steel, which can be divided into grade 8.8 and grade 10.9. Unlike ordinary bolts, bolts must be above grade 8.8.
选择时无需提出钢种和钢种要求。 摩擦式连接是钢结构工程中常用的一种。钢结构扭剪螺栓从受力特性上可分为摩擦式连接和压力式连接。 钢结构扭剪螺栓承压连接的连接面只需进行防锈处理即可。 然而,钢结构扭剪螺栓摩擦式具有连接紧密、受力好、抗疲劳、适合承受动载荷的优点。但连接面需做摩擦面处理,一般采用喷砂处理,喷砂后涂无机富锌漆。
Steel grade and steel grade requirements are not required for selection. Friction connection is a kind of common used in steel structure engineering. The torsional shear bolt of steel structure can be divided into friction connection and pressure connection. The connection surface of steel structure torsion shear bolt pressure bearing connection only needs to be treated with rust prevention. However, the friction type of torsional shear bolt in steel structure has the advantages of tight connection, good stress, fatigue resistance and suitable for bearing dynamic load. However, the connecting surface needs to be treated with friction surface. Generally, sand blasting is adopted, and inorganic zinc rich paint is applied after sand blasting.
钢结构扭剪螺栓可分由于螺栓结构和施工方法不同,分为大六角头高强螺栓和扭剪高强螺栓。 大六角头型与普通六角头粗螺栓相同。扭剪式螺栓头与铆钉头类似,但扭剪式螺纹端装有梅花夹头和可控制拧紧扭矩的环形槽这个区别需要注意。
Steel structure torsional shear bolts can be divided into large hexagon high-strength bolts and torsional shear high-strength bolts due to different bolt structures and construction methods. The large hexagon head type is the same as the common hexagon head thick bolt. The torsional shear bolt head is similar to the rivet head, but the difference between the torsional shear thread end equipped with a plum blossom collet and an annular groove that can control the tightening torque needs attention.
一个钢结构扭剪螺栓连接副包括三个部分:螺栓、螺母和垫圈。高强螺栓的结构和布置要求与普通螺栓相同。 那么一定要按照规范使用。大六角头只能用8.8高强螺栓,扭剪型高强螺栓只能用10.9高强螺栓。
A steel structure torsion shear bolt connection pair consists of three parts: bolt, nut and washer. The structure and layout requirements of high-strength bolts are the same as those of ordinary bolts. Then it must be used according to the specifications. Only 8.8 high-strength bolts can be used for large hexagon head and only 10.9 high-strength bolts can be used for torsional shear high-strength bolts.
以上就是为大家介绍的有关扭剪型电动扳手的详细的介绍,希望对您有所帮助.如果您有什么疑问的话,欢迎联系我们.我们将以的态度,为您提供服务
The above is a detailed introduction to the torsional shear electric wrench. I hope it will help you If you have any questions, please contact us We will provide you with professional service
